PDF下载产品参数
| 电压 Voltage (VDC) |
电阻 Resisstance (25℃) Ω/ 相 |
输出轴 步距角 Step angle |
电机 减速比 Motor Reduction Ratio |
齿轮箱减速比 Gearbox Reduction Ratio |
牵入转矩 Pull-in torque 300pps (mN·m) |
启动电压 Starting Voltage (300pps) |
启动转矩 Starting torque (mN·m) |
空载牵入频率 No-load Pull-in Frequency (pps) |
空载牵出频率 No-load Pull-out Frequency (pps) |
绝缘电阻 No-load Insulation Resisstance (DC500V)(MΩ) |
温升 Temperature Rise (K) |
噪声 Noise dB(A) |
| 12 | 200±7% | 7.5° /283 | 1/85.25 | 1/3.32 | ≥ 68.8 | 10VDC | ≥ 29.4 | ≥ 400 | ≥ 500 | ★≥ 100 | ≤ 60 | ≤ 45 |
机械尺寸
